What is TELEC? TELEC Review, Features

TELEC (Telecom Engineering Center) is Japan's mandatory certification for wireless products. TELEC certification includes test certification and type certification.

history

The Telecommunications Engineering Centre (TELEC), formerly MKK, was established in 1978.

Legal status

The Radio Law requires that designated radio equipment undergo model approval (i.e., technical regulations compliance certification). Certification is mandatory and the certification body is a registered body recognized by the MIC in the scope of designated radio equipment.

Certification Interpretation

TELEC certification includes test certification (Test Certification) and type certification (Type Certification).

1. Test certification is to verify each equipment unit, and the certification is only valid for each verified equipment unit;

2. Type certification refers to the verification of samples of a batch of equipment with the same design and manufacture. The certification is valid for the batch of equipment, but if the design or manufacture of the equipment changes, the equipment will need to be re-certified.

It is worth noting that the use of non-low-power radio stations and their terminal equipment requires a license from the MIC.

In addition, there are two cases for the conformity certification of telecommunications terminal equipment:

A. For ordinary telephone devices, JATE certification is only required according to the Telecommunications Business Act;

B. For wireless terminal equipment, in addition to JATE certification required by the Telecommunications Business Act, TELEC certification is also required in accordance with the Radio Act.

Certified Products

WIFI 2.4G

WIFI 2.5G

Bluetooth

2.4GHz frequency band

10GHz frequency band

315GHz band

902-928GHz frequency band

2G/3G/4G Products

No product certification required

433MHz

868MHz Products

TELEC certification does not open 2.9G and 5.8G to civilian use

Certification submission information

1. Technical Type Specification Form.

2. Declaration of Quality Management System.

3. Letter of Quality Control Confirmation MethodorManufacturer's ISO 9001 Certificate.

4. Letter of Construction Protection Confirmation.

5. Rated Power Declaration.

6. Antenna Report.

7. Test Reports (including Test Results, Test Setup Photos and Examinations carried out).

8. (Block Diagram, Schematic Diagram, Bill of Material, Parts Placement, IC Data Sheets, Internal and External Photos, Product Description, User manual, Operational/Technical Description, Description of Pheripherals/Accessories).

9. Label Information (Label Location, Label content); If you act as agentoras authorized representative of the manufacturer.

10. Power of Attorney/Authorization Letter.

Note: All submitted documents are recommended to be in Japanese, but English documents are also acceptable. Test reports can be in the language used by the local testing agency.

Certification steps

1. Product production: There must be a simple finished product, and the semi-finished product must provide a shell. Later, you can make a series and reserve several models for the perfect version and upgraded version. Click the avatar for specific operations.

2. Product valuation: Find Delai to directly conduct product evaluation. The evaluation price will be based on the product's wireless method, wireless module format, etc.

3. Determine the price: After both parties agree on the price, samples will be sent for testing, and product information and fixed-frequency hardware and software will be prepared.

4. Test the product: After receiving the sample, all TELEC items of the product will be tested. If the product fails to meet the standards, the product will be required to be rectified, and the re-test fee will be negotiated separately. It can be charged or not. If there is no problem with the product, it will proceed to the next step.

5. Draft certificate: After the product is tested, a draft of the product certification will be issued to the customer to confirm whether the information is correct. If it is correct, the relevant official documents will be issued. Certificate delivery and inquiry: After the case is completed, Delai will send the certificate and electronic file to the customer. Customers can only query on the website of the issuing agency. The Japanese TELEC website is only uploaded twice a year, once in February and once in July. So you have to wait for a while.
